You are here: SUKMA Tirta Persada - Distributor Pompa Air».GRUNDFOS Pumps

.GRUNDFOS Pumps

Grundfos - Pust

Overview

Grundfos_pust1Grundfos – Pust offers a full range of modular pumping stations, complete with all necessary piping, valves, level controls, etc. The range uses a modular concept and offers a large pit volume.The pump pit, pumps and controls can be combined to suit specific requirements for each individual application.
The pumping stations are made from durable polyethylene (PEHD). All pre-installed piping is either PE or stainless steel. As standard, the pumping stations are supplied with a PE top cover.The pumps are available in a variety of sizes. The standard range can be supplemented with customised versions as required.





Applications

Applications depend on the pump selected, and include:

  • Drainage
  • Effluent/rainwater/surface water
  • Wastewater.

Features and benefits

  • Modular flexibility
  • Corrosion-free materials
  • Increased sump volume prevents push-up
  • Easy installation
  • Sturdy construction
  • Inlet holes drilled on site
  • Sump design limits sludge and odour problems.

EBARA               GRUNDFOS              KSB              WILO          TSURUMI

Grundfos - HS Horizontal split case pumps

Overview

Grundfos-HS-modularThe Grundfos HS horizontal split case pump is a single-stage, non-self-priming, between bearing, centrifugal volute pump. The axially split design allows easy removal of the top casing and access to the pump components (bearings, wear rings, impeller, and shaft seal) without disturbing the motor or pipework.
The independent bearing housing allows for ease of maintenance without removing the top casing. The double volute design reduces the radial load on the shaft, extending component life, minimising vibration and providing quiet operation.
The HS pump also offers high pump efficiencies throughout the range.  High energy efficiency along with long pump life and easy maintenance add up to low life-cycle costs.
The HS pump is available in three configurations – pump with motor and baseframe, pump with baseframe, and bare shaft pump only.
The HS pump is ideal for custom applications and is available in a wide range of variants. The high efficiency and low life cycle costs make the HS ideal for any commercial building, water utility or industrial project.



Applications

Grundfos HS horizontal split case pumps are typically used in these applications:

  • Air-conditioning/heating systems
  • Public water supply
  • District cooling/heating plants
  • Cooling systems
  • Public waterworks
  • Process cooling
  • Irrigation.

Features and benefits

  • Grundfos-HS-Curve_PerformanceEasy to service: split case design
  • Double suction minimises axial load,which extends the life of the wear rings, shaft seals and bearings
  • Double volute reduces radial forces and minimises noise and vibration
  • Independent bearing housing design allows access to the pump components without removing the top half of the casing
  • High energy efficiency
  • Low life-cycle costs
  • Many product variants available











Technical data

  • Flow, Q :                     Max. 2500 m3/h
  • Head. H :                    Max. 148 m
  • Liquid temp :           0 °C to +100 °C
  • Operat, presure:     Max. 16 bar





EBARA               GRUNDFOS              KSB              WILO          TSURUMI

Grundfos CM, CME Booster

Grundfos CM, CME



Overview

Modern technologies have brought a high degree of comfort to people within their homes by providing a strong water supply. Grundfos offers complete tailored pressure boosting systems for domestic water supply that ensure optimal water pressure for household applications.

CM Booster, CME Booster comes in different versions:

  • CME Booster
  • CM Booster PM2
  • CM Booster PM1
  • CM Booster PT
  • CM Booster PS



The Grundfos CME Booster provides constant water pressure for a variety of domestic applications. This means that the end-user is no longer bothered by fluctuations in water pressure due to a rise or fall in demand, or from pump starts and stops. CME Booster keeps the pressure within the home up regardless of usage. The constant pressure feature provides the benefit of increased comfort.

In addition the CME Booster makes it possible to personalise the water pressure. By the touch of a button the pressure level is increased or decreased as desired.

Features

  • Constant pressure via integrated speed control
  • Compact
  • Robust, stainless steel
  • Easy installation
  • Dry-running protection
  • Low noise, 55 dB

Grundfos has taken the mystery out of controlling variable water pressure for the end-user. With a CM Booster PM2 complex operation and cryptic parameters are a thing of the past. The CM Booster combined with the PM2 provides adjustable pressure settings. The end-user is in control with regards to selecting the water pressure he prefers for pump start-up.

Features

  • Grundfos CM Centrifugal ModularCompact
  • Easy installation
  • Automatic resetting of alarms
  • Adjustable pressure settings
  • Dry-running protection
  • Anti cycling (leakage detection)
  • Maximum continuous operating time

The Grundfos CM Booster PM1 is a compact booster set for water supply in domestic applications. The pressure booster consists of a Grundfos CM pump and a Grundfos Pressure Manager PM1. The pressure manager allows the pump to start and stop automatically according to demand and protects the pump from dry-running.

Features

  • Compact
  • Easy installation
  • Automatic resetting of alarms
  • Adjustable pressure settings
  • Dry-running protection
  • Anti cycling (leakage detection)
  • Maximum continuous operating time

The Grundfos CM Booster PT is an automatic booster system for water supply in domestic and agricultural applications as well as other installations where small leakages are expected to occur.

The booster system consists of a Grundfos CM pump, a pressure tank and a pressure switch assembled into one unit.

The tank is delivered with the product and is easily connected to the CM pump. The system is now ready for use, with preset start pressure and compliant tank precharge pressure.

The pressure band is approximately 1 bar.

When the system has been connected to the pipework, it is all a matter of inserting the plug into a power supply socket, and the system is operational.

Features

  • CM pump
  • Pressure tank to minimise the number of pump starts
  • Motor protection (single-phase only)
  • Automatic operation.

The Grundfos CM Booster PS is an automatic booster system for water supply in domestic and agricultural applications as well as other installations where small leakages are expected to occur.

The booster system consists of a Grundfos CM pump, a 5-way valve and a pressure switch. A pressure tank must be fitted to complete the booster system.

Use your own pressure tank or order one of the Grundfos GT-tanks that make a perfect fit for your booster system.

The pressure band is approximately 1 bar.

When the system has been connected to the pipework, it is all a matter of inserting the plug into a power supply socket, and the system is operational.

Features

  • CM pump
  • pressure tank to minimise the number of pump starts
  • motor protection (single-phase only)
  • automatic operation.

Applications

  • in private homes
  • in summer houses and weekend cottages
  • on farms
  • in market gardens and other large gardens.
  • Blocks of flats
  • Schools
  • Small hotels or guest houses
  • Small office buildings

The pump is suitable for pumping of potable water and rainwater.



EBARA               GRUNDFOS              KSB              WILO          TSURUMI

GRUNDFOS The new ALPHA2



Overview

The improved Grundfos new ALPHA2 small circulator offers unrivalled energy efficiency based on proven Grundfos technologies and is the perfect choice for heating, air-conditioning and cooling applications with pumped media temperatures down to +2°C.

With the Grundfos new ALPHA2 you can stop worrying about complicated pump settings. Simply install the pump and leave it on the factory setting, AUTOADAPT. The new ALPHA2 will automatically analyse the heating system, find the optimum setting and continue to adjust its operation to changes in demand.

Applications

GRUNDFOS has made a few crucial design changes that allow you to use the new ALPHA2 now in cooling applications with pumped liquid temperatures down to +2°C. This means that the new ALPHA2 will not only cover your heating demands, but also up to 90% of your airconditioning and cooling demands. The new ALPHA2 with stainless steel pump housings can also be used in domestic hot-water recirculation systems.

The GRUNDFOS ALPHA2 is suitable for:

  • Systems with constant or varying flow
  • One pipe systems
  • Two pipe systems
  • Underfloor-heating
  • Domestic hot-water recirculation
  • Systems where night setback is required.


Energy efficiency:

Grundfos supports and encourages strict legislative demands for pump efficiency as part of our ongoing work to decrease energy bills and increase sustainability. And we are proud to say that the new
ALPHA2 – like its predecessors – is way ahead of its time. The EuP legislation requires all circulator pumps to have an Energy Efficiency Index (EEI) below 0.23 in 2015. The new ALPHA2 is with an EEI < = 0,15 way ahead of these common standards, which is why it has earned its place in the Grundfos Blueflux® family of highly energy efficient products.

Features and benefitsBetter performance with market leading efficiency

  • Better performance with market leading efficiency
    (EEI≤0.15) in a more compact design
  • New flow meter for trouble-shooting and balancing
  • AUTOADAPT selects best performance curve for
    efficiency and comfort
  • Innovative plug simplifies pump connection
  • Insulation shells included.



EBARA               GRUNDFOS              KSB              WILO

GRUNDFOS MTR, SPK, MTH, MTA

Overview

grundfos mthGrundfos MTR, SPK, MTH, MTA pumps are vertical multistage centrifugal pumps designed for pumping of cooling lubricants for machine tools, condensate transfer and similar applications.

The pumps are designed to be mounted on top of tanks with the pump stack immerged in the pumped liquid.

Grundfos MTR, SPK, MTH and MTA pumps come with various pump sizes and various numbers of stages to provide the flow, the pressure and the length required.

The pumps consist of two main components: The motor and the pump unit. The motor is a Grundfos standard MG motor designed to EN standards.

The pump unit consists of optimised hydraulics, various types of connections, a motor stool, a given number of chambers and various other parts.

Applications

The immersible pumps are suitable for liquid transfer in all applications where you have a tank. As main applications the following can be mentioned:

  • Lathes
  • Milling machines
  • Boring machines
  • Drilling machines
  • Machining centres
  • Grinding machines
  • Filtering systems
  • Swarf conveyors
  • Spark machine tools
  • Industrial washing machines
  • Cooling units.

Features and benefits

  • Flexible installation length
  • Wide performance range
  • Reliability
  • Service-friendly
  • Simple installation.





EBARA               GRUNDFOS              KSB              WILO

GRUDFOS SRP

Overview

The Grundfos range of recirculation pumps is the product of decades of engineering experience. Created to handle large flows with low heads, the SRP models are equally suitable for wastewater treatment plants and flood control.

GRUNDFOS SRP units come in three main variants – DN 300, 500 or 800 mm, fitted with motors from 0.8 to 24 kW. The units share many features with the AMG and AFG gear-driven mixers and flowmakers, making them instantly familiar to service staff and facilitating easy maintenance.

Recent developments include a triple sealing system for maximum protection of the mechanical shaft seal and a bracket that facilitates very easy installation.

Applications

The pumps are suitable for the following applications:

  • Re-circulation of sludge within sewage treatment plants
  • Storm water pumping.

Features and benefits

  • High efficiency stainless steel propeller
  • Electronic leak sensor in gearbox/shaft seal housing
  • Wide performance range
  • Strong axial gear in slim design for high hydrodynamic efficiency
  • Integrated overload and overheat protection
  • Good self-cleaning capabilities



EBARA               GRUNDFOS              KSB              WILO


Warning: Illegal string offset 'layout' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1264

Warning: Illegal string offset 'image_url' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1583

Warning: Illegal string offset 'images_id' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1585

Warning: Illegal string offset 'image_desc' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1586

Warning: Illegal string offset 'video_use_cbox' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1587

Warning: Illegal string offset 'video' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1588

Warning: Illegal string offset 'wordtube_id' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1589

Warning: Illegal string offset 'wordtube_use_cbox' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1590

Warning: Illegal string offset 'wordtube_height' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1591

Grundfos NK/NKG Pumps

Overview :

Grundfos NK/NKG pumps are used in water supply, industrial pressure boosting, industrial liquid transfer, HVAC (heating, ventilation and air-conditioning), irrigation and process industries.
Grundfos end-suction pumps are multi-purpose pumps suitable for a variety of different applications requiring reliable and cost-efficient supply. End-suction pumps are used in five main areas of application: water supply, industrial pressure boosting, industrial liquid transfer, HVAC (heating, ventilation and air-conditioning), and irrigation.

The pumps are all non-self-priming, single-stage, centrifugal volute pumps with axial suction port, radial discharge port and horizontal shaft. The Grundfos NK/NKG range comprises a complete series of long-coupled pumps that comply fully with either EN733 or ISO2858. The pumps are of the back pull-out design, enabling removal of the motor, coupling, bearing bracket and impeller without disturbing the pump housing or pipework. Even the largest pumps can thus be serviced by one person with a crane. The ISO2858 range of pumps are available with a bearing life of 100,000 hours, and can be fitted with double seals. They available in a stainless steel version as an option.

Applications

Grundfos offers a virtually limitless range of long-coupled (NK) end-suction pumps. Their sturdiness and reliability make them ideal for use in demanding environments such as the following:

  • District heating plants
  • Heating systems for blocks of flats
  • Air-conditioning systems
  • Cooling systems
  • Wash down systems
  • Other industrial systems.

Features and benefits

  • Optimised hydraulics in housing and impeller = unimpeded liquid flow
  • O-ring seal between pump housing and cover = no risk of leakage
  • Housing, impeller and wear ring in different materials = improved corrosion resistance, no sticking elements
  • Back pull-out design for easy dismantling for service
  • Pump is electro-coated to increase corrosion resistance
  • Available with IE1, IE2 and IE3  motors
  • PN 10/16 and 25 bar
  • Temperatures up to 180 °C
  • Available in a number of shaft seal and material variants.

EBARA               GRUNDFOS              KSB              WILO

Grundfos CR Pump Range

Overview

Grundfos-CR-rangeThe basic Grundfos CR pump range , which can be applied in almost any industrial solution, is already in itself the broadest range available. Through our modular approach, we have made it even broader.

The basic Grundfos CR pump range is available in four different materials: cast iron, two grades of stainless steel, and all-titanium. There are eleven flow sizes, capable of producing up to almost 50 bar of pressure, and with a variety of shaft seals, rubber materials and supply voltages.

Pump parts which are typically vulnerable to difficult liquids or particularly demanding operating conditions can be optimised for their purpose and designed for specific requirements.

Applications

CR pumps provide a complete range of pump solutions so that all applications, industrial and domestic, can benefit from the Grundfos touch. The applications that can be covered include the following:

  • Process water systems
  • Washing and cleaning systems
  • Seawater systems
  • Pumping of acids and alkalis
  • Ultrafiltration systems
  • Reverse osmosis systems
  • Swimming baths.

Features and benefits

  • Reliability
  • High efficiency
  • Service-friendly
  • Space-saving
  • Suitable for slightly aggressive liquids
  • High corrosion resistance
  • Single-pump solution making high pressures possible.
EBARA            GRUNDFOS           KSB          WILO        TSURUMI

Warning: Illegal string offset 'layout' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1264

Warning: Illegal string offset 'image_url' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1583

Warning: Illegal string offset 'images_id' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1585

Warning: Illegal string offset 'image_desc' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1586

Warning: Illegal string offset 'video_use_cbox' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1587

Warning: Illegal string offset 'video' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1588

Warning: Illegal string offset 'wordtube_id' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1589

Warning: Illegal string offset 'wordtube_use_cbox' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1590

Warning: Illegal string offset 'wordtube_height' in /home/dis10007/public_html/wp-content/themes/InnovationScience2/cms/php/cp_renderer.php on line 1591

Grundfos Hydro MPC - Booster set

Hydro MPC booster sets consist of two to six identical CRI(E)/CR(E) pumps connected in parallel and mounted on a common base frame provided with a control cabinet and all the necessary fittings.

As standard, Hydro MPC booster sets consist of two to six identical CRI(E)/CR(E) pumps connected in parallel and mounted on a common base frame provided with a control cabinet and all the necessary fittings.

Hydro MPC booster sets are supplied as complete, pre-assembled and thoroughly tested booster sets, ready to install.
Most of the booster sets are available with either CR(I) pumps and/or CR(I)E pumps.

Grundfos Hydro MPC booster sets are divided into seven groups based on control variants.
Hydro MPC’s outstanding reliability and efficiency is the best possible base for our booster systems. Equipped with the intelligent CU 351 controller, the Hydro MPC boosters offer an even higher efficiency and reduced energy costs. The end result is complete control, optimum flexibility of booster output, and unbeatable efficiency at all times.
Hydro MPC booster sets are fitted with hygienic designed manifolds.

Water Supply
Grundfos Hydro MPC boosters are ideal for mains water supply systems and for pressure boosting in multi-storey buildings. The needs for water in multi storey buildings vary a lot during the course of the day – this demands much from the equipment used. With a Grundfos booster system, it is easy to provide optimum user comfort by maintaining constant water pressure at all levels and at all times.

Industry
Industries can also benefit greatly from a booster solution from Grundfos. If you require constant pressure in the face of highly variable flows, Grundfos has the solution. Even the most demanding applications will benefit from the accuracy and advanced pump control in a Grundfos Hydro MPC booster.

Irrigation
A Grundfos Hydro MPC booster system can help conserve water and optimise crop yields by responding to pre-set minimum and maximum levels. Grundfos Hydro MPC is lenient on the pipe net in golf course irrigation systems and adapts the performance automatically to any number of sprinklers at any pressure zone during the irrigation cycle. It is benefits like these that make Grundfos the perfect choice for irrigation systems.

EBARA               GRUNDFOS              KSB              WILO
