.KSB Pumps

KSB-CPKN-SX Sprinkler systems to VdS and fire protection Pump







Design

KSB-CKPN-MODULARHorizontal, long-coupled, single-stage volute casing pump in back pull-out design. Replaceable shaft protecting sleeves and casing wear rings.

Applications

Sprinkler systems to VdS and fire protection.













Overview of technical data

Type of bearing Ball bearings
Casing partition Radially split
Drive frequency 50 Hz / 60 Hz
Type of drive Electric motor, turbine, I.C. engine
Drive voltage Low voltage
No. of impeller entries Single entry
Impeller material (EN standard) 1, 4408
Type of installation Long- coupled
Type of coupling Direct
Type of lubrication Oil lubrication
Max. permissible fluid temperature 20
Nozzle position End suction
Maximum rated pressure (discharge) 25 BAR
Pull-out design Yes
Pump set location Dry installed
Shaft material (EN standard) 1. 4057;1.4462
Suction characteristics Non- priming
Suitable for drinking water Yes
Type of impeller Radial; Closed;Multi-vane impeller
Type of connection Flange
Casing material (EN standard) JS1025
eClass assignment 36410101; 36410000;36410100
Maximum head 163, 00
Minimum head 84, 00 m
Shaft seal type Mechanical seal; Gland packing
Main applications Industry and process engineering; Building services;Water
Casing material Cast iron
Maximum discharge-side pressure 25 bar
Maximum drive rating 250 kW
Type of installation Stationary
Maximum flow rate 468 m³/h
Minimum flow rate 82 m³/h
Maximum speed of rotation 3 1/min

Fire protection is a question of experience

Application-cpkn-sx_KSB
KSB leads the European sprinkler pump market – with good reason. Our experience in fire protection stretches back more than
40 years. And KSB makes its products on every continent. That
international presence is a major advantage in fire protection –
we know our way through all the standards, certifications and
regulations and are represented by fire protection experts in over
100 countries. We have the right pumps and components to
match central Europe’s VdS standard, the UK’s LPC BS 5306-2,
Spain and Portugal’s CEPREVEN, European standard EN 12845,
NFPA20/FM/UL in the USA, and a host of other national standards.
For us, quality includes delivering ideal technology. But that is
just part of our first-class service. More than 1,600 KSB specialists
in over 100 service centres provide skilled help, fast. Whether
your building is just being planned or older than all its occupants,
KSB stops fires before they really get started. Water relief!



EBARA            GRUNDFOS           KSB          WILO        TSURUMI

KSB-MHD Slurry Pumps



Design

KSB-MHD-ModularDesigned to provide high flow/medium head with high efficiency for high
volume transportation in long pipelines.

Horizontal end suction construction. Single wall pump shell
with replaceable suction side liner; four vane impeller or
three vane option for larger size solids.



Applications

Mineral processing (oil sands, copper, gold, iron ore, nickel, phosphate, coal)

• Power Generation
• Aggregate (sand & gravel)
• Ash Handling
• Flue Gas Desulfurization
• Thickener & Tailings
• Mine Dewatering
• Industrial Slurries
• Dredge



Wear Parts

1. Impeller is designed for wear-resistant operation in
highly abrasive slurries using GIW’s flow simulation
computer program.
2. Two aramid gaskets aid in the removal of the impeller.
3. Replaceable suction liner facilitates pump internal
inspection and minimizes wear part usage and cost.
Liner can be rotated at intervals to increase wear life.
4. Pump shell is computer designed to optimize wear
and efficiency.



Shaft Seal

KSB-MHD-LSA-Shaftseal5. Replaceable wear plate maximizes stuffing box life.
Reduced water consumption options available.
6. Shaft sleeve with fused carbide wear resistant coating
to maximize packing life



Mechanical End

KSB MHD-Curves7. Robust stiffened shaft to improve the wear life
of the mechanical end and stuffing box.
8. Impeller release ring for safe and easy impeller
removal. Feature is standard on larger pump sizes.
9. Spring retainer ring locates the thrust bearing
preload springs for correct axial thrust load.
10. Radial bearings are a heavy duty, self-aligning,
double-row, spherical roller-type design.
11. Split-cartridge bearing assembly offers ease of
inspection and maintenance.
12.Accurate impeller clearance adjustments are easily
made with the adjusting screw.
13. Labyrinth seals protect bearings.



Quick Alignment

14. Rabbet fits machined in the pedestal support the
shell and provide component alignment.



EBARA            GRUNDFOS           KSB          WILO        TSURUMI

KSB-Rio N / Z N Circulator Pumps with Manual Speed Control



Design

KSB-Rio N / RIO Z N

Maintenance-free, glandless wet rotor pump, flanged or screw-ended, with three speed levels; in twin pump design (Rio Z) for standby operation with integrated swing check valve or, on option, peak load operation (parallel operation).

KSB-Rio.N-ZN

Applications

Hot water heating systems, heat recovery systems and cooling circuits in air-conditioning systems.



Operating modes

▪ Different speed levels



Automatic functions

▪ Full motor protection with integrated trip electronics
(from size 25-70 motor protection to be provided by the
operator)





Overview of technical data
Type of bearing Plain bearings
Drive Electric motor
Drive frequency 50 Hz / 60 Hz
Type of drive Electric motor
Drive voltage Low voltage
Connection to power supply 400 V, 3~; 230 V, 1~
Impeller material (EN standard) POLYPROPYLEN
Type of installation In- line
Type of coupling None
Type of lubrication Oil / Product lubrication
Max. permissible fluid temperature 120 °C
Nozzle position In- line
Maximum rated pressure (discharge) PN 10
Pump set location Dry installed
Shaft material (EN standard) X 46 CR 13
Suction characteristics Non- priming
Type of casing Volute casing
Type of impeller Closed / Radial
Type of connection Screw- ended, flange
UNSPSC classification 4015150300
Casing material (EN standard) EN- GJL-250
eClass assignment 36410105; 36410101;36410100;36410000
Maximum head 4, 00 m
Installation position Horizontal or vertical
Shaft seal type Seal- less
Main applications Building services; Water
Casing material Cast iron
Maximum discharge-side pressure 10 bar
Type of installation Stationary
Maximum flow rate 76 m³/h
Maximum speed of rotation 2. 800 1/min



EBARA            GRUNDFOS           KSB          WILO        TSURUMI

KSB - Movitec B-Multistage vertical high-pressure centrifugal pump



Design

Ksb-movitec-BKSB-Movitec-B Multistage, vertical, high-pressure centrifugal pump in ring-section design with suction and discharge nozzles of identical nominal diameters arranged opposite to each other (in-line design), close-coupled. ATEX-compliant version available.



Applications

Spray irrigation, irrigation, washing, water treatment, fire-fighting and pressure booster systems, hot water and cooling water recirculation, boiler feed systems etc.
Sizes
2, 4, 6, 10, 15, 25, 90







Overview of technical data

Barrel casing Yes
Type of bearing Plain bearings
Casing partition Radially split
Diffuser material (EN standard) 1. 4301;1.4404
Drive frequency 50 Hz / 60 Hz
Type of drive Electric motor
Drive voltage Low voltage
No. of impeller entries Single entry
Impeller material (EN standard) 1. 4301;1.4404
Type of installation In- line
Type of coupling Direct
Type of lubrication Oil / Product lubrication
Max. permissible fluid temperature 140 °C
Nozzle position In- line
Maximum rated pressure (discharge) 40 BAR
Pump set location Dry installed
Shaft material (EN standard) 1. 4305;1.4401
Suction characteristics Non- priming
Suitable for drinking water Yes
Type of impeller Radial
Type of connection Flange
Type of stage casing Stage casing with diffuser
UNSPSC classification 4015150300
Casing material (EN standard) 1. 4301;1.4401;JL 1040
eClass assignment 36410101
Maximum head 249, 00 m
Installation position Vertical
Shaft seal type Mechanical seal
KSB_Movitec-B-Curves























Main applications























Industry and process engineering; Water;Building services

Casing material Chrome nickel steel
Maximum discharge-side pressure 40 bar
Maximum drive rating 45 kW
Type of installation Stationary
Maximum flow rate 112, 80 m³/h
Maximum speed of rotation 2. 900 1/min



EBARA            GRUNDFOS           KSB          WILO        TSURUMI

KSB-Magnochem-Standardized chemical pump with mag-drive

Design KSB-Magnochem-Standardized chemical pump with mag-drive

KSB-magnetic-drive-chemical-centrifugal-pumps-6194-2723279Horizontal, seal-less, mag-drive volute casing pump in back pull-out design to ISO 2858 / EN 22 858 / ISO 5199, single-stage, single-entry, with radial impeller. Design to ATEX.





Applications

Handling of aggressive, toxic, explosive, valuable, flammable, malodorous or harmful liquids in the chemical, petrochemical and general industry.





Overview of technical data

Type of bearing Ball and plain bearings
Casing partition Radially split
Drive frequency 50 Hz / 60 Hz
Type of drive Electric motor
Drive voltage Low voltage
No. of impeller entries Single entry
Heatable Yes
Impeller material (EN standard) JS 1025; JL 1040;NORIDUR 1.4593;1.4408
Type of installation Long- coupled
Type of coupling Direct
Type of lubrication Oil / Product lubrication
Max. permissible fluid temperature 300 °C
Nozzle position End suction
Maximum rated pressure (discharge) PN 25
Pull-out design Yes
Pump set location Dry installed
Shaft material (EN standard) C45+ N;1.4462
Suction characteristics Non- priming
Type of casing Volute casing
Type of impeller Multi- vane impeller;Closed;Closed / Radial;Radial
Type of connection Flange
Casing material (EN standard) JS 1025; GP240GH+N;1.4408;NORIDUR 1.4593
eClass assignment 36410101; 36410100;36410000
Maximum head 225, 00 m
Minimum head 3, 50 m
Installation position Horizontal
Shaft seal type Magnetic drive
Main applications Industry and process engineering; Energy
KSB-Magnochem.-CurveCasing material



















Cast stainless steel; Special KSB material;Cast steel;Cast iron;Nodular cast iron

Maximum discharge-side pressure 25 bar
Maximum drive rating 160 kW
Type of installation Stationary
Maximum flow rate 1. 400 m³/h
Minimum flow rate 1 m³/h
Maximum speed of rotation 3. 500 1/min





EBARA            GRUNDFOS           KSB          WILO        TSURUMI

KSB-Amarex KRT INDUSTRY H, C1, C2



Design

KSB-amarex-krt-jacket-cooledVertical, single-stage submersible motor pump made of wear-resistant industrial materials in close-coupled design, various impeller types, for wet or dry installation, stationary and transportable version. Design to ATEX.



Applications

Handling of all types of abrasive or aggressive waste water in water and waste water engineering as well as industry, especially untreated sewage containing long fibres and solid substances, fluids containing gas / air, as well as raw, activated and digested sludge; sea water desalination.









Overview of technical data

Type of bearing Rolling element bearings
Casing partition Radially split
Drive Electric motor
Drive frequency 50 Hz / 60 Hz
Type of drive Electric motor
Drive voltage Low voltage
Connection to power supply < 690 V, 3~
Explosion protection ATEX II 2 G T3; ATEX II 2 G T4
No. of impeller entries Single entry
Impeller material (EN standard) JN 3029; 1.4517
Type of installation Close- coupled
Type of coupling None
Type of lubrication Oil lubrication
Max. permissible fluid temperature 60 °C
Nozzle position End suction
Maximum rated pressure (discharge) PN 16
Pump set location Wet well
Shaft material (EN standard) 1. 4462;C45+N
Suction characteristics Non- priming
Type of casing Volute casing
Type of impeller Open; Multi-vane impeller;Radial;Closed;Free flow impeller
Type of connection Flange
Casing material (EN standard) 1. 4517;JN 3029
eClass assignment 36410103; 36410101
Free passage 120 mm
Maximum head 100, 00 m
Installation position Vertical
Shaft seal type Mechanical seal
Amarex KRT_5K_колесоMain applications















Water; Oil / Gas;Energy;Industry and process engineering;Mining / Dredges;Waste water / sewage



Casing material White cast iron; Cast duplex steel
Maximum discharge-side pressure 10 bar
Maximum drive rating 200 kW
Type of installation Stationary; Transportable
Maximum flow rate 2. 400 m³/h
Maximum speed of rotation 3. 500 1/min





EBARA            GRUNDFOS           KSB          WILO        TSURUMI

KSB-CPKN-Standardized chemical pumps



KSB-CPKN-Standardized chemical pump with reinforced bearing bracket

ksb-cpkn1-modularsDesign

Horizontal, radially split volute casing pump in back pull-out design to EN 22 858 / ISO 2858 / ISO 5199, single-stage, single-entry, with radial impeller. Also available as variant with “wet” shaft, conical seal chamber, heatable volute casing (CPKNO-CHs) and/or semi-open impeller (CPKNO). Design to ATEX.

Applications

Handling of aggressive liquids in the chemical and petrochemical industries as well as in refinery and fire-fighting systems, handling of brine.

type-series-booklet-cpkn-140566_2bOverview of technical data

Type of bearing Rolling element bearings
Casing partition Radially split
Drive frequency 50 Hz / 60 Hz
Type of drive Electric motor
Drive voltage Low voltage
No. of impeller entries Single entry
Heatable Yes
Impeller material (EN standard) NORIDUR 1. 4593;JL 1040;1.4408
Type of installation Long- coupled
Type of coupling Direct
Type of lubrication Oil lubrication
Max. permissible fluid temperature 400 °C
Nozzle position End suction
Maximum rated pressure (discharge) PN 25
Pull-out design Yes
Pump set location Dry installed
Shaft material (EN standard) 1. 4462;1.5680;C 45+N;1.7709
Standard ISO 5199; ISO 2858;EN 22858
Suction characteristics Non- priming
Type of casing Volute casing
Type of impeller Closed; Radial
Type of connection Flange
Casing material (EN standard) NORIDUR 1. 4593;1.4408;JS 1025;GP240GH+N
eClass assignment 36410000; 36410100;36410101
Maximum head 275, 00 m
Minimum head 2, 00 m
Installation position Horizontal
Shaft seal type Mechanical seal
Main applications Energy; Industry and process engineering
Casing material Cast stainless steel; Ni-Resist;Cast duplex steel;Cast steel;Nodular cast iron
Maximum discharge-side pressure 25 bar
Maximum drive rating 3. 200 kW
Type of installation 00
Maximum flow rate 4. 800 m³/h
Minimum flow rate 1 m³/h
Maximum speed of rotation 3. 500 1/min



EBARA            GRUNDFOS           KSB          WILO        TSURUMI

KSB-RPH-Process Pumps






Ksb-RPH is Horizontal, radially split volute casing pump in back pull-out design to API 610, 11th edition, or ISO 13709 (heavy duty), with radial impeller, single-stage, single-entry, centreline pump feet; with inducer, if required. Design to ATEX.



Applications

Refineries, petrochemical and chemical industry, power stations.



Low maintenance costs

  • The selection of a balancing system for the specific duty point markedly reduces axial forces and extends the bearing life.
  • The double volute (DN 80 and above) reduces radial thrust and prevents shaft deflection.
  • This reduces the load on bearings and mechanical seal.
  • Mechanical seals to ISO 24109 / API 682 in cartridge design are easy to install/remove for maintenance.

Low operating costs

  • A choice of more than 70 hydraulic systems enables optimum pump selection to API with higher efficiencies.

Overview of technical data

KSB-RPH.Curves

Type of bearing Rolling element bearings
Casing partition Radially split
Drive frequency 50 Hz / 60 Hz
Drive voltage Low voltage, high voltage
No. of impeller entries Single entry
Heatable Yes
Type of installation Long- coupled
Type of coupling Direct
Type of lubrication Oil lubrication
Max. permissible fluid temperature 450 °C
Nozzle position End suction
Maximum rated pressure (discharge) PN 100
Pull-out design Yes
Pump set location Dry installed
Standard API 610; ISO 13709
Suction characteristics Non- priming
Type of casing Volute casing
Type of impeller Multi- vane impeller;Closed;Closed / Radial;Radial
Type of connection Flange
UNSPSC classification 4015150300
eClass assignment 36410101; 36410000;36410100
Maximum head 285, 00 m
Installation position Horizontal
Shaft seal type Mechanical seal
Main applications Oil / Gas;Industry and process engineering
Maximum discharge-side pressure 110 bar
Maximum drive rating 3. 200 kW
Type of installation Stationary
Maximum flow rate 4. 800 m³/h
Maximum speed of rotation 3. 500 1/min



EBARA            GRUNDFOS           KSB          WILO        TSURUMI

KSB-HPK



KSB-hpk-modular-1Design

KSB-HPK Series

Horizontal, radially split volute casing pump in back pull-out design to EN 22 858 / ISO 2858 / ISO 5199, single-stage, single-entry, with radial impeller. TÜV certification to TRD on option. Design to ATEX.



Applications

KSB-hpk-app



KSB-HPK Series

Handling of hot water and thermal oil in piping or tank systems, particularly in medium-sized and large hot water heating systems, forced circulation boilers, district heating systems, etc.

Overview of technical data

Type of bearing Rolling element bearings
Casing partition Radially split
Drive frequency 50 Hz / 60 Hz
Type of drive Electric motor
Drive voltage Low voltage
No. of impeller entries Single entry
Impeller material (EN standard) JS 1030; JL 1040;1.4408
Type of installation Long- coupled
Type of coupling Direct
Type of lubrication Oil lubrication
Max. permissible fluid temperature 240 °C
Nozzle position End suction
Maximum rated pressure (discharge) PN 40
Pull-out design Yes
Pump set location Dry installed
Shaft material (EN standard) C45+ N
Suction characteristics Non- priming
Type of casing Volute casing
Type of impeller Radial; Closed
Type of connection Flange
Casing material (EN standard) JS 1025; 1.7706;GP240GH+N
eClass assignment 36410000; 36410100;36410101
Maximum head 275, 00 m
Minimum head 2, 00 m
Installation position Horizontal
Shaft seal type Mechanical seal; Gland packing
Main applications Industry and process engineering; Energy;Building services
Casing material Cast steel; Nodular cast iron
Maximum discharge-side pressure 40 bar
Maximum drive rating 3. 200 kW
Type of installation Stationary
Maximum flow rate 4. 800 m³/h
Minimum flow rate 1 m³/h
Maximum speed of rotation 3. 500 1/min



EBARA            GRUNDFOS           KSB          WILO        TSURUMI

KSB-Hyamat® VP





KSB-MovitecDesign

KSB-Hyamat® VP

Fully automatic package pressure booster system, with 2 to 6 vertical high-pressure pumps and continuously variable speed control of each pump by PumpDrive speed control system.

For fully electronic control of the required supply pressure.

Configuration and functions to DIN 1988, Part 5. Automated with BoosterControl and PumpDrive.









Applications

KSB-Hyamat® VP

Pressure boosting in residential buildings, hospitals, office buildings, hotels, department stores, industry, etc.

Overview of technical data

KSB-Hyamat-VPType of bearing Plain bearings
Drive frequency 50 Hz
Type of drive Electric motor
Drive voltage Low voltage
Type of first impeller Closed / Radial
Other impeller types Closed / Radial
Impeller material (EN standard) 1. 4301
Type of coupling Direct
Type of lubrication Oil / Product lubrication
Max. permissible fluid temperature 70 °C
Nozzle position In- line
Number of pumps 4
Maximum rated pressure (discharge) PN 16
Pump set location Dry installed
Suction characteristics Non- priming
Suitable for drinking water Yes
Type of connection Screw- ended, flange
Type of stage casing Stage casing with diffuser
UNSPSC classification 4015150300
Casing material (EN standard) 1. 4301
eClass assignment 36410101
Maximum head 160, 00 m
Minimum head 6, 00 m
Maximum inlet pressure 10 bar
Installation position Vertical
Shaft seal type Mechanical seal
Main applications Industry and process engineering; Water;Building services
Casing material Chrome nickel steel
Maximum discharge-side pressure 16 bar
Maximum drive rating 7, 50 kW
Type of installation Stationary
Maximum flow rate 660 m³/h
Maximum speed of rotation 2. 900 1/min
Standby pump Yes
Type of connection Indirect and direct



EBARA            GRUNDFOS           KSB          WILO        TSURUMI

Pages:« Prev1234Next »
