Water Management

Water Management

Grundfos-TP Vertical in line pump



Grundfos-TP Vertical in line pump



Grundfos vertical in-line volute pumps are used in a number of applications including air conditioning and heating. The pumps are all single-stage, in-line centrifugal volute pumps with standard motors and mechanical shaft seals.

The pumps are close-coupled, meaning that the pump and motor are separate units. Consequently, the pumps are less sensitive to impurities in the pumped liquid compared to similar canned rotor pumps.

Max flow: 4,500 m3/h
Max motor size: 630 kW




Main product characteristics

  • Optimised hydraulics for high efficiency
  • Low noise level
  • High efficiency motors (EFF1) as standard
  • Top-pull-out design for easy dismantling during service
  • Mechanically and hydraulically balanced impeller to increase motor bearing and shaft seal lifetime
  • The entire pump is electro-coated to increase corrosion resistance
  • Available in single and twin pump design
  • Available in a number of shaft seal and material variants
  • PN 6,10, 16 and 25 bar.
  • Temperature up to 150C


















EBARA            GRUNDFOS           KSB          WILO        TSURUMI

Wilo - VeroLine-IPS



Wilo – VeroLine-IPS

Wilo-Veroline-IPs (1)Design

Glanded pump in in-line design with threaded connection or flange connection


For pumping cold and hot water (in accordance with VDI 2035) without abrasive substances in heating, cold water and cooling water systems

Special features / product benefits

  • Worldwide availability of the standard motors used
  • Bidirectional mechanical seal with forced flushing

Technical data

  • Permissible temperature range ‐10°C to +140°C
  • Mains connection 3~230 V, 3~400 V, 50 Hz
  • Protection class IP 55
  • Nominal diameter Rp 1 and DN 40
  • Max. operating pressure, 10 bar or 6 bar for flange connection

ype key

  • Example IPS 40 GRD
  • IPS In-line pump
  • 40 Nominal diameter DN of the pipe connection
  • GRD Mechanical seal

Special features/product advantages

  • Worldwide availability of the standard motors used
  • Bidirectional mechanical seal with forced flushing


  • Single-stage, low-pressure centrifugal pump in in-line design with
  • Mechanical seal or stuffing box
  • Threaded or flange connection with pressure measuring connection R 1/8
  • Standard motor


  • Pump housing and lantern: EN‐GJL‐200
  • Impeller: Plastic
  • Shaft: 1.4021
  • Mechanical seal: BVEGG; other mechanical seals on request

Scope of delivery

  • Pump
  • Installation and operating instructions



EBARA            GRUNDFOS           KSB          WILO        TSURUMI


Wilo-Sub TWU 4





Water-supply unit with submersible-motor pump, control and complete accessories.


Water-supply unit for self-sufficient water supply in the domestic sector

  • Washing machines
  • Garden sprinkling
  • Transferring by pumping and filling
  • Taps for process water

Special features / product benefits

  • Simple assembly, installation and operation
  • Low-wearing due to floating impellers
  • Reliable motor, due to high starting torque
  • Integrated non-return valve

Technical data

  • Mains connection: 1~230 V, 50 Hz
  • Immersed operating mode: S1
  • Fluid temperature: 3‐30 °C
  • Minimum motor flow: 0.08 m/s
  • Max. sand content: 50 g/m3
  • Max. number of starts: 20/h
  • Max. immersion depth: 200 m
  • Protection class: IP 68
  • Pressure connection: Rp 1¼




EBARA            GRUNDFOS           KSB          WILO        TSURUMI







Vertical close-coupled, in-line circulator pump with volute casing and standardized motor.
Hot water heating systems, cooling circuits, air-conditioning, water and service water supply systems, industrial recirculation systems.



Overview of technical data
Type of bearing Ball bearings
Casing partition Radially split
Drive IEC standardized motor, electric motor
Drive frequency 50 Hz / 60 Hz
Type of drive Electric motor
Drive voltage Low voltage
Connection to power supply 400 V, 3~
Impeller material (EN standard) 1. 4408;CC480K-GS;JL1040
Type of installation Close- coupled
Type of coupling Direct
Type of lubrication Oil lubrication
Max. permissible fluid temperature 140 °C
Nozzle position In- line
Maximum rated pressure (discharge) PN25
Pull-out design Yes
Pump set location Dry installed
Shaft material (EN standard) 1. 4057;C45
Suction characteristics Non- priming
Type of casing Volute casing
Type of impeller Closed / Radial
Type of connection Flange
Casing material (EN standard) JL1040; JS 1025
eClass assignment 36410000; 36410100;36410101;36410105
Maximum head 97, 00 m
Installation position Horizontal or vertical
Shaft seal type 00
Main applications Industry and process engineering; Water;Building services
Casing material Carbon steel
Type of installation Stationary
Maximum flow rate 1. 900 m³/h
Minimum flow rate 60 m³/h
Maximum speed of rotation 1. 750 1/min


EBARA               GRUNDFOS              KSB              WILO          TSURUMI

Wilo-Comfort CO-/COR-Helix V/CC





Wilo CurveDesign

Highly efficient, ready-for-connection water supply unit (non self-priming) with 2 to 6 vertically arranged glanded stainless steel high-pressure multistage centrifugal pumps from the Helix V series connected in parallel, including Comfort Controller CC (available with and without frequency converter).


  • Fully automatic water supply and pressure boosting in residential, commercial and public buildings, hotels, hospitals, department stores and for industrial systems.
  • Pumping of potable water, process water, cooling water, fire water (apart from fire-extinguishing systems in accordance with DIN 14462) or other water mixtures that do not attack the materials used chemically or mechanically and do not contain abrasive or long-fibre constituents

Special features / product benefits

  • Heavy-duty system with Helix V series stainless steel high-pressure multistage centrifugal pumps for all requirements contained in DIN 1988 (EN 806)
  • High-efficiency pump hydraulics in conjunction with IE2 standard motors
  • Hydraulics of entire system are pressure-loss optimised
  • 2- 6 vertically arranged Helix V series high-pressure multistage centrifugal pumps switched in parallel
  • Easy-to-use controller CC, with expanded functions, memory-programmable microcomputer control and graphics-ready touchscreen, menu-prompted input of operating parameters, available with or without frequency converter for stepless control of base-load pump
  • Customised units on request


Wilo-boster_0Technical data

  • Mains connection 3~230 V / 400 ± 10%, 50 Hz
  • Fluid temperature max. 50°C (70°C optional)
  • Operating pressure 16 bar (25 bar optional)
  • Inlet pressure 10 bar
  • Nominal connection diameters on discharge side R 1½ ‐ DN 200
  • Nominal connection diameter on the intake side R 1½” – DN 200
  • Nominal speed 2850 rpm
  • Protection class IP 54 (control device CC)
  • Fuse on mains side AC 3 according motor power and EVU regulations
  • Approved fluids (other fluids on request):
    • Potable water and secondary hot water
    • Cooling water
    • Fire water (wet line; for dry lines on request – comply with separate specifications of DIN 1988 (EN 806) and of fire-protection authorities.)

    Note on fluids: Approved fluids are generally water mixtures which do not chemically or mechanically attack the materials used and do not contain either abrasive or fibrous matter



EBARA               GRUNDFOS              KSB              WILO          TSURUMI


KSB-Hya-Eco VP




KSB-Hya Eco VP Fully automatic package pressure booster system, with 2 to 3 vertical high-pressure pumps and continuously variable speed adjustment of each pump for fully electronic control of the required supply pressure, with two standard volt-free changeover contacts for fault indication. Configuration and functions to DIN 1988, Part 5. Automated with BoosterControl and PumpDrive.

Building service, Residential buildings, hospitals, office buildings, hotels, department stores, industry, and other applications.


Overview of technical data
Type of coupling Direct
Pump set location Dry installed
Casing material (EN standard) 1. 4301
Maximum head 100, 00 m
Maximum inlet pressure 6 bar
Installation position Vertical
Shaft seal type Mechanical seal
Main applications Industry and process engineering; Water;Building services
Maximum drive rating 7, 50 kW
Type of installation Stationary
Maximum flow rate 70 m³/h
Maximum speed of rotation 2. 850 1/min
Standby pump Yes
Type of connection Direct
Operating mode Cascade and variable




EBARA               GRUNDFOS              KSB              WILO          TSURUMI



• Civil, Industrial, farming, fire-fighting, boosting systems
• Water treatment plants (reverse osmosis, filtrations)
• Irrigation system
• Washing system
• Movement of hot and cold water for heating, cooling and air-conditioning system.
• Boiler feeding
• Movement of moderately aggressive chemical liquids without solids.
• Impeller, diffusers, casing cover, outer casing, shaft sleeve, coupling covers,
fixing in contact with liquid: AISI 304 stainless steel
• Bottom casing: AISI 304 stainless steel (EVM) – cast iron (EVMG),
• Motor bracket and base: cast iron (not in contact with the pumped liquid)
• Bearings (in contact with liquid): tungsten carbide
• Mechanical seal: Silicon carbide/carbon/Viton
• Shaft: AISI 316 stainless steel
• Tie rods and fixings not contact with liquid: zinc coated stainless steel

EBARA Corporation was established in 1912 as a pump manufacturer and today EBARA is the world’s foremost manufacturer
of pumps and pump system. EBARA is proudly presenting Vertical Multi-stage pump type EVM, manufacture with great
experience of EBARA in design and production of stamped stainless steel pumps. EBARA EVM pumps offer technically advance


Screenshot_3designs to meet most market demands, including pumping of aggressive liquid.
Two standard pump options are available to satisfy most of the market requirements:
– EVM(G): Bottom casing in cast iron, other liquid contact parts in SS304 stainless steel for general
water supply usage
– EVM(L): All wetted contact parts in SS316 stainless steel for aggressive liquid pumping operation.
Optional materials available upon request: All wetted contact parts in SS304 stainless steel for industrial
pumping applications.




EBARA               GRUNDFOS              KSB              WILO          TSURUMI

Grundfos Hydro Multi-E - Booster set

Hydro multi-EHydro Multi-E is an innovative pressure booster system specially designed for building service applications.

As standard, Hydro Multi-E booster sets consist of two to four identical CRE pumps connected in parallel and mounted on a common base frame provided with a control cabinet and all the necessary fittings.

The control of the booster set builds on the master and slave principal where one pump is the master pump and where the other pumps act as slaves.
Hydro Multi-E booster sets are supplied as complete, pre-assembled and thoroughly tested booster sets, ready to install. The set point is easily adjusted via the Grundfos R100 remote control or from the control panel. The advanced control takes care of other adjustments to maintain constant pressure and optimum comfort.

Hydro Multi-E is built on Grundfos CRE pumps, known for their extremely high efficiency and reliability. The speed-controlled motors provide unique control functionality, which increases the comfort of the user and decreases operating costs. High quality materials are used throughout.


  • Extreme high reliability and efficiency
  • Perfect adaptation to demand
  • Constant pressure
  • Small foot print
  • Simple to use
  • Turnkey booster set ready for installation – plug ‘n’ pump unit
  • Hygienic designed manifolds


EBARA               GRUNDFOS              KSB              WILO          TSURUMI


Grundfos - HS Horizontal split case pumps


Grundfos-HS-modularThe Grundfos HS horizontal split case pump is a single-stage, non-self-priming, between bearing, centrifugal volute pump. The axially split design allows easy removal of the top casing and access to the pump components (bearings, wear rings, impeller, and shaft seal) without disturbing the motor or pipework.
The independent bearing housing allows for ease of maintenance without removing the top casing. The double volute design reduces the radial load on the shaft, extending component life, minimising vibration and providing quiet operation.
The HS pump also offers high pump efficiencies throughout the range.  High energy efficiency along with long pump life and easy maintenance add up to low life-cycle costs.
The HS pump is available in three configurations – pump with motor and baseframe, pump with baseframe, and bare shaft pump only.
The HS pump is ideal for custom applications and is available in a wide range of variants. The high efficiency and low life cycle costs make the HS ideal for any commercial building, water utility or industrial project.



Grundfos HS horizontal split case pumps are typically used in these applications:

  • Air-conditioning/heating systems
  • Public water supply
  • District cooling/heating plants
  • Cooling systems
  • Public waterworks
  • Process cooling
  • Irrigation.

Features and benefits

  • Grundfos-HS-Curve_PerformanceEasy to service: split case design
  • Double suction minimises axial load,which extends the life of the wear rings, shaft seals and bearings
  • Double volute reduces radial forces and minimises noise and vibration
  • Independent bearing housing design allows access to the pump components without removing the top half of the casing
  • High energy efficiency
  • Low life-cycle costs
  • Many product variants available






Technical data

  • Flow, Q :                     Max. 2500 m3/h
  • Head. H :                    Max. 148 m
  • Liquid temp :           0 °C to +100 °C
  • Operat, presure:     Max. 16 bar



EBARA               GRUNDFOS              KSB              WILO          TSURUMI

Tsurumi - TRN


Tsurumi-TRN-cutSubmersible aspirating aerators ranging in size from 1 HP to 50 HP. The TRN is designed for very high oxygen transfer efficiency, to mix and entrained solids with out adding oxygen from an expensive blower installation.

 Tsurumi TRN Series Features

Non-clog impellers.

Horsepower ranges from 1 hp to 50 hp.

Can operate in water depth of 32 feet with supplemental blower.

Powerful stirring and mixing capabilities for convectional circulation.

Compact shape and design.

The open rotor of the Tsurumi TRN series suctions a large volume of water for the motor power through the pump basket. This water is then mixed with air and distributed horizontally in all directions through the channels of the guide ring.

The top of the rotor is hollow and allows the air that has been suctioned in to fill the area aroundthe shaft seal so that it can mix with the water at the rotor.

One consequence of this is that alayer of air is formed separating the shaft seal from the medium and thereby substantially increasing the life of the shaft seal.

Another effect is that the water that is suctioned in is oxygenated with tiny air bubbles, effectively aerating the waste water.

EBARA               GRUNDFOS              KSB       TSURUMI       WILO
