KSB-MEGA Horizontal, end suction, modified volute casing
Application
The GIW Mega Slurry is a high-performance, lowmaintenance slurry pump recommended for coarse
or fine particles from solids laden waste water to
aggressive slurries of an abrasive and/or corrosive
nature.Consult factory for corrosive applications.
Design
Horizontal, end suction, modified volute casing
pump includes three vane, open design impeller
for large solids passage and good wear
characteristics over a broad operating range. The
single stage, compact arrangement allows easy
maintenance of wet end components. The back
pull-out design permits removal of the mechanical
end without disturbing the wet end or piping.
Casing
The pump casing is horizontal volute casing, one piece casting with integral mounting foot.
Shaft
The shaft is dry design, protected by an easily renewable shaft sleeve in the gland sealing area. The impeller threads on the
pump end of the shaft and a keyway is provided on the drive end to attach the coupling or pulley.
Shaft Sealing
The entry of the shaft into the pump is sealed by standard gland packing or by an optional mechanical seal.
