KSB Mega CPK-Horizontal radially split volute casing pump

Design

KSB Mega CPK
Horizontal, radially split volute casing pump in back pull-out design to EN 22 858 / ISO 2858 / ISO 5199, single-stage, single-entry, with radial impeller. Also available as variant with “wet” shaft. ATEX-compliant version available.

KSB-Mega CPK

▪ Volute casing pump

▪ Horizontal installation

▪ Back pull-out design

▪ Single-stage

▪ Meets the technical requirements to ISO 5199

▪ Dimensions and ratings to ISO 2858 complemented by pumps of nominal diameters DN 25, DN 200 and above



Pump casing

▪ Single or double volute, depending on the pump size
▪ Radially split volute casing
▪ Volute casing with integrally cast pump feet
▪ Replaceable casing wear rings (as required)
Impeller type
▪ Closed radial impeller with multiply curved vanes
Shaft seal
▪ Gland packing
▪ Commercial single and double mechanical seals
▪ Commercial cartridge seals
▪ Shaft fitted with a replaceable shaft protecting sleeve in the shaft seal area
Alternative:
▪ Version without shaft protecting sleeve with “wet shaft” (in Europe and
Northern Asia only)
Bearings
Bearings:
▪ Medium-duty
– Radial bearing: cylindrical roller bearing
– Fixed bearing: paired angular contact ball bearings / double-row angular
contact ball bearing
▪ Economy
– Floating bearing assembly: deep groove ball bearings
Lubrication:
▪ Oil lubrication
▪ Grease lubrication

Applications

Handling of aggressive liquids in the chemical and petrochemical
industries as well as in refinery

Overview of technical data

KSB-Mega CPK Configuration
Type of impeller Closed / Radial
Type of installation Long- coupled
Maximum drive rating 90 kW
Impeller material (EN standard) 1. 4593 / 1.4517 / A995GRCD4MC;GP240GH+N/ A216GRWCB;JL1040/ A48CL35
Type of bearing Ball bearings
Drive frequency 50 Hz / 60 Hz
Maximum speed of rotation 4 1/min
Maximum flow rate 1. 160 m³/h
Maximum discharge-side pressure 25 bar
Casing material (EN standard) DUPLEX STAINLESS STEEL 1. 4593/;GREY CAST IRON JL1040 / A48CL3;STAINLESS STEEL 1.4408 / A743;STEEL GP240GH+N/ A216 GR WCB
No. of impeller entries Single entry
Integrated control system Yes
Minimum flow rate 2 m³/h
Suction characteristics Non- priming
Drive voltage Low voltage
Pull-out design Yes
Pump set location Dry installed
Heatable Yes
Max. permissible fluid temperature 400 °C
Main applications Industry and process engineering; Oil / Gas
Type of casing Volute casing
Type of connection Flange
Type of lubrication Grease / Product lubrication
Type of drive Electric motor
Installation position Horizontal
Level indication Grease lubrication
Shaft material (EN standard) ALLOY STEEL 1. 7709+QT+SR;DUPLEX STAINLESS STEEL 1.4462;STEEL C45+N
Type of coupling Direct
Shaft seal type Gland packing; Mechanical seal
Maximum head 162, 00 m
Maximum rated pressure (discharge) PN25
Minimum head 2, 00 m
Nozzle position End suction
Casing partition Radially split



EBARA                    GRUNDFOS                     KSB

KSB-Amarex KRT - G, G1, G2, GH

Amarex KRT with highly efficient submersible motors

With highly efficient IE3* submersible motors the pumps of the Amarex KRT® series are a true innovation on the market. KSB’s extremely energy-efficient motors can be integrated into pump stations as standard. The pump sets can be supplied with or without explosion protection

Amarex_KRT-EKSB’s in-house development work has enabled these pump sets to be mechanically and electrically optimised for the special requirements of waste water transport. The Amarex KRT motors’ electrical and magnetic design fulfils the requirements of the IE3* efficiency class up to a drive rating of 850 KW.

Combining these motors with a wide range of hydraulic systems for handling waste water enables KSB to provide pump sets offering superb efficiency and dependable operation for every application. Save energy effectively

Design

Vertical, single-stage submersible motor pump in close-coupled design, various impeller types, for wet or dry installation, stationary and transportable version. Design to ATEX.

Applications

Handling of all types of abrasive or aggressive waste water in water and waste water engineering as well as industry, especially untreated sewage containing long fibres and solid substances, fluids containing gas / air, as well as raw, activated and digested sludge; sea water desalination.



Pump sets of installation types P and S

KSB-Amarek-KRT-Guide railare designed for continuously submerged operation. The motor is cooled by the fluid
handled on the motor surface. Operation with the motor outside the fluid handled is
possible for short periods.

Pump sets of installation type K

are suitable for continuous operation with the motor outside the fluid. Cooling is
effected by means of air convection.

Operating data

Capacity Q up to 6200 m3/h, 1700 l/s
Head H up to100 m
Motor power P2 from 0,8 kW to 320 kW
Temperature of
pumped liquid t up to 60 oC
Enclosure type IP 68 to EN 60 529 / IEC 529
additional flameproof versions ATEX II 2G T3 or T4

Drive

Three-phase asynchronous motor
400 V (variants: 230 V, 500 V, 690 V)

Material

Standard version of cast iron
Material variants of wear-resistant chilled iron and
corrosion-resistant duplex stainless steel



Overview of technical data

Type of bearing Rolling element bearings
Casing partition Radially split
Cutter Yes
Drive frequency 50 Hz / 60 Hz
Type of drive Electric motor
Drive voltage Low voltage
Connection to power supply < 690 V, 3~
Explosion protection ATEX II 2 G T3; ATEX II 2 G T4
Impeller material (EN standard) JN 3029; JL 1040;1.4517
Type of installation Close- coupled
Type of coupling None
Type of lubrication Grease lubrication
Max. permissible fluid temperature 60 °C
Nozzle position End suction
Maximum rated pressure (discharge) PN 16
Pump set location Dry installed; Wet well
Shaft material (EN standard) C45+ N;1.4021
Suction characteristics Non- priming
Type of casing Volute casing
Type of impeller Open; Closed;Multi-vane impeller;Free flow impeller;Radial;Single-vane impeller;Diagonal;Cutter
Type of connection Flange
Casing material (EN standard) 1. 4517;JL 1040;JN 3029
eClass assignment 36410101; 36410103
Free passage 240 mm
Maximum head 120, 00 m
Minimum head 1, 00 m
Installation position Horizontal or vertical
Shaft seal type Mechanical seal
Main applications Energy; Water;Industry and process engineering;Mining / Dredges;Waste water / sewage;Building services
Casing material Cast iron
Maximum discharge-side pressure 12 bar
Maximum drive rating 850 kW
Type of installation 00; Transportable;Stationary
Maximum flow rate 10. 080 m³/h
Minimum flow rate 0, 60 m³/h
Maximum speed of rotation 3. 500 1/min



EBARA              GRUNDFOS              KSB             WILO           TSURUMI



KSB - Movitec A PumpDrive-vertical, high-pressure centrifugal pump

Design

KSB-MovitecPumpDriveKSB – Movitec A PumpDrive

Multistage, vertical, high-pressure centrifugal pump in ring-section design with suction and discharge nozzles of identical nominal diameters arranged opposite to each other (in-line design), close-coupled. ATEX-compliant version available.



Applications

Spray irrigation, irrigation, washing, water treatment, fire-fighting and pressure booster systems, hot water and cooling water recirculation, boiler feed systems etc.
Sizes
6 (LHS), 45, 65

Overview of technical data

Type of bearing Plain bearings
Drive frequency 50 Hz / 60 Hz
Type of drive Electric motor
Drive voltage Low voltage
Type of first impeller Radial
Other impeller types Radial
Type of installation In- line
Type of coupling Direct
Type of lubrication Oil / Product lubrication
Max. permissible fluid temperature 120 °C
Pump set location Dry installed
Stage casing material (EN standard) 1. 4301;1.4404
Suitable for drinking water Yes
Type of stage casing Stage casing with diffuser
UNSPSC classification 4015150300
Casing material (EN standard) 1. 4301;1.4401;JL1040
eClass assignment 36410101
Maximum head 401, 00 m
Installation position Vertical
Shaft seal type Mechanical seal
Main applications Industry and process engineering; Water;Building services
Casing material Chrome nickel steel
Maximum discharge-side pressure 40 bar
Maximum drive rating 45 kW
Type of installation Stationary
Maximum flow rate 75 m³/h
Maximum speed of rotation 2. 900 1/min



EBARA               GRUNDFOS              KSB              WILO          TSURUMI

KSB-Rio C Hot water heating systems and heat recovery systems





KSB-Rio C Hot water heating systems and heat recovery systems



Design

Maintenance-free, glandless wet rotor pump, screw-ended, with three speed levels.



KSB-RIO-C-Dim

Applications

Hot water heating systems, heat recovery systems and cooling circuits in air-conditioning systems.

KSB-RIO-C-CURV



Overview of technical data

Type of bearing Plain bearings
Drive Electric motor
Drive frequency 50 Hz
Type of drive Electric motor
Drive voltage Low voltage
Connection to power supply 230 V, 1~
Impeller material (EN standard) KUNSTSTOFF
Type of installation In- line
Type of coupling None
Type of lubrication Oil / Product lubrication
Max. permissible fluid temperature 110 °C
Nozzle position In- line
Maximum rated pressure (discharge) PN 10
Pump set location Dry installed
Shaft material (EN standard) EDELSTAHL X40 CR13
Suction characteristics Non- priming
Suitable for drinking water Yes
Type of casing Volute casing
Type of impeller Closed / Radial;Closed
Type of connection Thread
UNSPSC classification 4015150300
Casing material (EN standard) EN- GJL-200
eClass assignment 36410101; 36410100;36410000;36410105
Maximum head 5, 60 m
Minimum head 0, 25 m
Installation position Any
Shaft seal type Seal- less
Main applications Building services; Water
Casing material Cast iron
Maximum discharge-side pressure 10 bar
Maximum drive rating 0. 10 kW
Type of installation Stationary
Maximum flow rate 3, 60 m³/h
Maximum speed of rotation 2. 200 1/min



EBARA            GRUNDFOS            KSB            WILO          TSURUMI

KSB - Etanorm GPV / CPV Single-stage volute casing pump,for vertical installation in closed tanks under atmospheric pressure

Design

KSB – Etanorm GPV / CPV
Single-stage volute casing pump, ratings to EN 733, for vertical installation in closed tanks under atmospheric pressure. Up to an immersion depth of 2000 mm.



Applications

Handling of neutral degreasing and phosphatizing solutions, wash water with degreasing agents, dipping paints, etc.



 KSB-Etanorm GPV-W-CPV-W-modularSectional drawing

1 Motor housing 2, 3 Rolling element bearings
4 Motor stool 5 Cover plate
6 Shaft 7 Overflow opening
8 Intermediate pipe 9 Shaft passage
10 Casing cover 11 Impeller
12 Suction nozzle 13 Discharge nozzle
14 Riser 15 Volute casing
16 Clearance gap























To transport the pump/pump set suspend it from the lifting tackle as shown below.

KSB-Etanorm GPV-W-CPV-W.dia







Fig. 1: Transporting the pump set without/with cover plate up to motor size 160



KSB-Etanorm GPV-W-CPV-W-hor



Fig. 2: Transporting the pump set without/with cover plate up to motor size 160 for
larger installation depths



Overview of technical data

Type of bearing Rolling element bearings
Casing partition Radially split
Drive frequency 50 Hz / 60 Hz
Type of drive Electric motor
Drive voltage Low voltage
No. of impeller entries Single entry
Maximum submergence 535 mm
Impeller material (EN standard) 1. 4408;JL 1040
Type of coupling Direct
Type of lubrication Grease lubrication
Max. permissible fluid temperature 70 °C
Nozzle position Variable
Maximum rated pressure (discharge) PN 10; PN 16
Pump set location Wet well
Shaft material (EN standard) 1. 4462;C45+N
Standard EN 733
Suction characteristics Non- priming
Top plate Yes
Type of casing Volute casing
Type of impeller Radial; Closed
Type of connection Flange
Casing material (EN standard) 1. 4408;JL 1040
eClass assignment 36410101; 03641000;36410100
Maximum head 100, 00 m
Minimum head 1, 50 m
Installation position Vertical
Shaft seal type Shaft seal ring
Main applications Industry and process engineering; Waste water / sewage
Casing material Cast iron; Stainless steel
Maximum discharge-side pressure 10 bar
Maximum drive rating 90 kW
Type of installation Stationary
Maximum flow rate 750 m³/h
Minimum flow rate 3 m³/h
Maximum speed of rotation 3. 500 1/min





EBARA            GRUNDFOS             KSB            WILO           TSURUMI

KSB Amacan K - Submersible motor pump with non-clogging impeller





Design

KSB-Amacan K-ModularKSB Amacan K – Wet-installed submersible motor pump with non-clogging impeller, singlestage, single-entry, for installation in discharge tubes, explosion protection to ATEX II G2 T3.



















Applications

Handling of pre-cleaned, chemically neutral waste water, industrial effluents and sewage, fluids not containing any stringy substances pre-treated by screens and sills, as waste water, mixed water and activated sludge pump in effluent treatment plants, irrigation and drainage pumping systems.

Function

KSB-Amacan K-instThe fluid enters the pump axially via the inlet of the pump casing (1) and is
accelerated outward in a radial flow by the rotating impeller (2). The required energy
is transmitted from the electric motor (7) to the impeller (2) via the shaft (4). In the
pump casing (11) the kinetic energy of the fluid is converted into pressure energy.
The rotational movement diverts the fluid flow in axial direction. The casing wear
ring (12) prevents any fluid from flowing back from the casing into the inlet of the
pump casing. At the rear side of the impeller, the shaft enters the casing via the
discharge cover (3). The shaft passage through the discharge cover is sealed towards
the fluid by a shaft seal (10). The shaft runs in rolling element bearings (5 and 8),
which are supported by a bearing housing (9) and a bearing bracket (6).





Standard

KSB-Amacan K-Diagram Temperature monitoring of the motor
▪ Temperature monitoring at the lower bearing
▪ Leakage monitoring of the mechanical seal system
▪ Leakage sensors in the motor/connection space









 Flamepaths for explosion-proof motors

KSB-Amacan K-Explosion proof





















Overview of technical data

Type of bearing Rolling element bearings
Casing partition Radially split
Drive Electric motor
Drive frequency 50 Hz / 60 Hz
Type of drive Electric motor
Drive voltage Low voltage
Connection to power supply 380 V, 400 V, 690 V, 3~
Explosion protection ATEX II 2G T3
No. of impeller entries Single entry
Impeller material (EN standard) 9. 4460;JL 1040
Type of installation Close- coupled
Type of coupling None
Type of lubrication Grease lubrication
Max. permissible fluid temperature 40 °C
Nozzle position In- line
Pump set location Wet well
Shaft material (EN standard) 1. 4021QT700;C45+N;1.4057
Suction characteristics Non- priming
Type of casing Tubular casing
Type of impeller Multi- vane impeller;Radial;Closed
Casing material (EN standard) JL 1040
eClass assignment 36410103; 36410100;36410000
Free passage 180 mm
Maximum head 30, 00 m
Minimum head 1, 00 m
Installation position Vertical
Shaft seal type Mechanical seal
Main applications Water; Waste water / sewage;Mining / Dredges
Casing material Cast iron
Maximum drive rating 320 kW
Type of installation Stationary
Maximum flow rate 7. 200 m³/h
Minimum flow rate 140 m³/h
Maximum speed of rotation 1. 200 1/min



EBARA              GRUNDFOS               KSB              WILO             TSURUMI

KSB-KWP-Bloc Horizontal, radially split volute casing pump with various impeller types





Design

KSB-KWP-Bloc Horizontal, radially split volute casing pump with various impeller types

Horizontal, radially split volute casing pump in closecoupled design, single-stage, single-entry, available with various impeller types: non-clogging impeller and free-flow impeller.

The hydraulic system and the motor are firmly connected and form a close-coupled
unit. Impeller (7) and motor (10) are arranged on a common shaft (5)

KSB-KWP-Curves

Applications

Handling of pre-treated sewage, waste water, all types of slurries without stringy substances and pulps up to 5 % bone dry with a maximum density of 1.1 kg/dm3.









Function

The steadily rotating impeller (7) of the centrifugal pump transfers mechanical
energy to the fluid passing through.

KSB-KWP-Bloc-ModularThe fluid enters the pump axially via a suction nozzle (6) and is accelerated outward
in a cylindrical flow by the rotating impeller (7). The flow profile of the pump casing
converts the kinetic energy of the fluid into pressure energy. The fluid leaves the
pump via the discharge nozzle (2).
The casing is fitted with a replaceable wear plate (1). The diagonal clearance gap
prevents frequent deviation of the flow in the clearance gap heading in the direction
of the suction nozzle. This ensures a longer service life if solids-laden fluids are
handled.
The casing is closed by a discharge cover (3). The shaft (5) enters the casing via this
discharge cover. A shaft seal (8) provides reliable sealing towards the atmosphere.
The shaft is supported by oil-lubricated rolling element bearings (9). The motor (10) is
connected to the casing via an intermediate lantern (4)





Overview of technical data

Type of bearing Rolling element bearings
Casing partition Radially split
Drive frequency 50 Hz / 60 Hz
Type of drive Electric motor
Drive voltage Low voltage
No. of impeller entries Single entry
Impeller material (EN standard) ERN; NORIDUR 1.4593
Type of installation Close- coupled
Type of coupling Direct
Type of lubrication Grease lubrication
Max. permissible fluid temperature 100 °C
Nozzle position End suction
Maximum rated pressure (discharge) PN 10
Pull-out design Yes
Pump set location Dry installed
Shaft material (EN standard) 1. 4021;1.4462
Suction characteristics Non- priming
Type of casing Volute casing
Type of impeller Closed; Multi-vane impeller;Free flow impeller;Radial
Type of connection Flange
Casing material (EN standard) NORIDUR 1. 4593;JL 1040
eClass assignment 36410000; 36410100;36410103;36410101
Free passage 70 mm
Maximum head 100, 00 m
Minimum head 2, 00 m
Installation position Horizontal or vertical
Shaft seal type Mechanical seal
Main applications Industry and process engineering
Casing material Duplex steel; Cast iron
Maximum discharge-side pressure 10 bar
Maximum drive rating 22 kW
Type of installation Stationary
Maximum flow rate 330 m³/h
Minimum flow rate 4 m³/h
Maximum speed of rotation 3. 500 1/min



EBARA            GRUNDFOS             KSB            WILO           TSURUMI

KSB-Etaseco Seal-less volute casing pump in back pull-out design with fully





Design

KSB-Etaseco Horizontal / vertical, seal-less volute casing pump in back pull-out design with fully enclosed canned motor

KSB-etaseco-mudular copyLow noise emission, with radial impeller, singlestage, single-entry, pump casing connecting dimensions to EN 733.








Applications

Handling of aggressive, flammable, toxic, volatile, or valuable liquids in the chemical and petrochemical industry, in environmental engineering and the general industry.



Drive

KSB-Etaseco-CurvesThree-phase, asynchronous canned motor, enclosure IP 55,
without explosionproof status. Thermal motor protection by
means of PTC thermistors. The motor design is in accordance
with IEC 60 034 (DIN VDE 0530).











Overview of technical data

Type of bearing Plain bearings
Casing partition Radially split
Drive IEC standardized motor
Drive frequency 50 Hz / 60 Hz
Type of drive Electric motor
Drive voltage Low voltage
Connection to power supply 220/ 400/690 V, 3~
No. of impeller entries Single entry
Impeller material (EN standard) JL1040; JS1025
Type of installation Close- coupled
Type of coupling Direct
Type of lubrication Oil / Product lubrication
Max. permissible fluid temperature 140 °C
Nozzle position End suction
Maximum rated pressure (discharge) PN 16
Pull-out design Yes
Pump set location Dry installed
Shaft material (EN standard) 1. 4021
Suction characteristics Non- priming
Type of casing Volute casing
Type of impeller Multi- vane impeller;Closed;Closed / Radial;Radial
Type of connection Flange
Casing material (EN standard) JS1025; JL1040
eClass assignment 36410100; 36410101;36410000
Maximum head 100, 00 m
Minimum head 9, 00 m
Installation position Horizontal or vertical
Shaft seal type Canned motor pump
Main applications Industry and process engineering
Casing material Cast iron; Nodular cast iron
Maximum discharge-side pressure 16 bar
Maximum drive rating 18 kW
Type of installation Stationary
Maximum flow rate 250 m³/h
Minimum flow rate 3 m³/h
Maximum speed of rotation 3. 500 1/min



EBARA            GRUNDFOS             KSB            WILO           TSURUMI

KSB - HGM-RO High-pressure pumps for reverse osmosis systems





KSB-HGM-RO high-pressure pump – reliable drinking water treatment in reverse osmosis systems

KSB_HGM_RO-modular



Drinking water production in RO systems requires a high-pressure pump of top reliability which provides continuously economical operation. KSB responds to this need with an ideal solution: the HGM-RO high-pressure pump.













High-pressure pumps  HGM-RO High-pressure pumps for reverse osmosis systems need to be able to handle the harsh conditions which prevail in seawater desalination plants.

KSB-HGM-RO-Curves



KSB has opted for radially split high-pressure pumps.

Their radially split design makes HGM-RO high-pressure pumps particularly robust, enabling them to cope with the extreme conditions of drinking water treatment in seawater desalination.







Benefits of using KSB’s radially split high-pressure pumps in reverse osmosis systems:

HGM-RO-Radially-split-designMinimum energy input, low operating costs

Excellent NPSH value thanks to axial inflow with suction stage impeller. Continuously high efficiencies.



Compact design

Internal, product-lubricated plain bearings with a short bearing span ensure smooth running and therefore high pump availability and reliability as well as a long service life of wear parts.



Corrosion-resistant design

The HGM-RO high-pressure pump is made of duplex or super duplex stainless steels. Its corrosion-resistant design (e.g. dry shaft) translates into a long service life.

KSB-HGM-RO-01k

Low monitoring requirements

There is no need for an additional lubrication system, and the pump does not require any vibration or bearing temperature monitoring. This saves both initial and operating costs for the pump set.

Minimum maintenance costs

Because of its axial inlet, the HGM-RO high-pressure pump has just one mechanical seal, which minimises spare parts costs. The ring section design ensures top reliability in the extreme conditions of reverse osmosis systems. No lubrication systems are required. The mechanical seal is easy to replace.

Reduced construction costs

The pump’s compact design, low weight and smooth running lower the requirements to be met by the foundation. Flexible connection branches facilitate connection to the system piping.



Easier to install and dismantle than axially split pumps

The pump can be dismantled and reassembled from either side. The wear parts are easily accessible.



EBARA            GRUNDFOS            KSB            WILO          TSURUMI

KSB-CHTC – Horizontal, multistage high-pressure barrel type pump



 KSB-CHTC – Horizontal, multistage high-pressure barrel type pump

Design

KSB-CHTCHorizontal, high-pressure barrel-type pump with radial impellers, single- and double-entry, multistage, with flanges / weld end nozzles to DIN and ANSI.



Applications

Handling of feed water and condensate in power stations and industrial facilities, generation of pressurized water for bark peeling machines and descaling equipment.



High operating reliability

KSB-CHTC-Modular1. In the case of axial thrust balancing by double drum, the
residual axial thrust is absorbed by a tilting-pad thrust
bearing

2. Optimisation of casing design in terms of line of action of
force

3. Adaptation of pump casing to rotor deflection line

Long service life

4. Transmission of axial forces to the bearing housing by
means of a cardanic ring avoids wear on the thrust bearing

5. Low NPSH value thanks to fitting of suction stage impeller as a standard

Ease of service

6. Replacement of pump cartridge without having to remove
the pump from the piping

7. Maintenance work on wear parts with no opening of the
pump

Reduced operating costs

8. Efficiency improvement through cellular surface wear
rings



Overview of technical data

Barrel casing Yes
Type of bearing Plain bearings
Casing partition Radially split
Drive frequency 50 Hz / 60 Hz
Type of drive Electric motor, turbine
Drive voltage Low voltage, high voltage
Type of first impeller Single entry
No. of impeller entries Single / Double entry
Other impeller types Closed / Radial
Type of installation Long- coupled
Type of coupling Geared variable speed coupling; Gear;Variable speed coupling;Direct
Type of lubrication Grease / Oil / Pressurized oil lubrication
Max. permissible fluid temperature 200 °C
Nozzle position Variable
Maximum rated pressure (discharge) PN160; PN250; PN320; PN400
Pull-out design Yes
Pump set location Dry installed
Suction characteristics Non- priming
Type of connection Flange, weld ends
Type of discharge casing Annular casing
Type of stage casing Stage casing with diffuser
Type of suction casing Annular casing
eClass assignment 36410000; 36410101;36410100
Maximum head 4. 000,00 m
Installation position Horizontal
Shaft seal type Mechanical seal
Main applications Energy; Industry and process engineering
Casing material Carbon steel; Chrome steel
Maximum discharge-side pressure 400 bar
Maximum suction pressure 30 bar
Type of installation Stationary
Maximum flow rate 1. 278 m³/h
Maximum speed of rotation 6. 750 1/min



EBARA              GRUNDFOS              KSB             WILO           TSURUMI



Pages:1234Next »
